M-FCC Multi Flow Control Cube CORE I

M-FCC Multi Flow Control Cube CORE I

类别: 泵技术
订货号 : 3601.0017.01

The Multi Flow Control Cube is used to measure and control the flow and pressure of the thermal fluid. It can be used with Huber temperature control units with Pilot ONE technology.

The flow measurement is based on the Coriolis measuring method. An individual calibration for the liquid used is not necessary and can be used universally for different temperature control media.



In comparison to FCC, M-FCC has an independent controller, i.e. control takes place autonomously and communication with the Pilot ONE of the temperature control unit is not necessary. With M-FCC, multi-circuit control can be realised.

In most applications, a single temperature control unit is connected to an FCC for the first control loop. Additional M-FCC products are added for all further control loops.



Temperature range: -40 ... 150 °C

Min. volume flow: 0,9 l/min

Max. volume flow: 95 l/min

fluid connection: M38x1,5 male

Power supply: 90-240V 1~/2~ 50/60Hz
