M-FCC Multi Flow Control Cube TURB

The Multi Flow Control Cube is used to measure and control the flow and pressure of the thermal fluid. It can be used with Huber temperature control units with Pilot ONE technology. The flow measurement is carried out via a turbine flow meters (TURB). The TURB flow meters can be calibrated for various liquids (e.g. silicone oils or water-glycol mixtures).

In comparison to FCC, M-FCC has an independent controller, i.e. control takes place autonomously and communication with the Pilot ONE of the temperature control unit is not necessary. With M-FCC, multi-circuit control can be realised.

In most applications, a single temperature control unit is connected to an FCC for the first control loop. Additional M-FCC products are added for all further control loops.

Temperature range: -90 ... 250 °C

Min. volume flow: 0,9 l/min

Max. volume flow: 95 l/min

Fluid connection: M38x1,5 male

Power supply: 90-240V 1~ 50/60Hz
