ADR Automated Drain & Refill System

Temperature range: -45 °C....150 °C

Fluid connection: M38x1,5 male

Dimensions (WxDxH): 397x545x586 mm

Compressed air max.: 4 bar

Power supply: 90-240V 1~/2~ 50/60Hz

Protection class: IP20

Useable: Free-Standing Unistats, Unimotive and Unichiller Tower

Heat transfer fluids: water-ethylene glycol mixtures

Solenoid valves: electrically controlled

Notes:

- Please specify the used device with serial number when ordering.

- Safety device against overpressure not included in the scope of delivery.

- The connection of the fluid return line to the temperature control system must be carried out by others.

- No excess pressure is permitted in the TCU during the active return of the liquid, i.e. a pressure equalisation must have been completed prior to the return of the fluid to the expansion vessel.
